Tool Cutter Grinder

Tool Cutter Grinder
Tool Cutter Grinder
Product Code : TCLM 1
Product Description

Having worked in this arena, we have acquired rich domain expertise and knowledge to undertake and successfully manufacture, trade and supply Tool & Cutter Grinder. Used for various types of grinding and cutting, these products find application in heavy engineering, electrical & engineering, textile, printing, automobile, aerospace and many more such industries. Our team of quality controllers inspect these products in order to ascertain their rigidness and capability of re sharpening of different jobs that runs from H.S.S to carbide tip tools and cutters. Modified as per the specifications given by our clients, Tool & Cutter Grinder is available with us at very affordable rates.

USE OF MACHINE

  • To grind side face & slitting cutter.

  • To grind helical reamer.

  • To grind hob, radius & teeth cutter.

  • To grind taps.

  • To grind woodruff-cutter.

  • To grind end mill cutter.

  • To grind taper shank drill, reamer & end mill cutter.

  • To grind carbide tip cutter & end mill-cutter, Etc..

SPECIFICATION

Largest diameter of cutter than be ground 250 mm.
Maximum admit between centers 260 mm.
Maximum length of cutting edges ground 150 mm.
Grinding wheel speeds 4500 RPM.
Swing diameter and standard center 250 mm.
Working surface of table 450 x 120 mm.
Longitudinal traverse 175 mm.
Cross traverse 150 mm.

PAKING & INSTALLATION PARAMETERS
Floor area occupied 690 x 430 mm.
Height of the machine 1375 mm.
Weight of the machine with standard accessories 300 kg.
Electric Motor 3 phase 0.5 H.P. 2800 RPM .

STANDARD EQUIPMENT
Steady with centers 2 Nos.
Universal tilting head 1 Nos.
Relieving attachment 1 Nos.
Diamonds dressing stand 1 Nos.
Grinding disc wheel-dia 1 Nos.
Grinding taper cup wheel-dia 1 Nos.
Threaded mandrill with sleeve and nu 1 Nos.

 SPECIAL ACCESSORIES

  • Radius grinding attachment

  • Universal machine vice

  • Machine lamp

  • Diamond lamp

  • Tapper mandrill hardened and ground
