Horizontal Metal Cutting Bandsaw Machine

Horizontal Metal Cutting Bandsaw Machine
Horizontal Metal Cutting Bandsaw Machine
Product Code : BLM 1
Brand Name : Laxman Machine Tools
Product Description

Established as one of the leading manufacturers, suppliers, traders and service providers, we offer optimum-grade Horizontal Metal Cutting Bandsaw Machine. These machines, fabricated with finest quality raw materials backed by an expert panel of professionals, are ideal for all kinds of sawing processes. We engineer our products in compliance with industry standards and norms. Furthermore, our quality team tests the Horizontal Metal Cutting Bandsaw Machine to rule out the possibility of any defects. In order to suit the requirements of our clients, these machines are available with us in various technical specifications at industry leading prices.


TECHNICAL SPECIFICATION

CUTTING CAPACITY

Model

BLM-1

BLM-1HS

BLM-2

BLM-3

Round

MM

175

200

300

350

Square

MM

175 X 175

175 X 175

300 X 300

350 X 350

Rectangular

MM

200 X 140

200 X 140

400 X 150

450 X 150

DRIVE

Drive Motor

----------

0.5 H.P., 1440 RPM

1.0 H.P., 1440 RPM

1.5 H.P., 1440 RPM

1.5 H.P., 1440 RPM

Coolant Pump

----------

0.15 H.P., 440 Volts

0.15 H.P., 440 Volts

0.15 H.P., 440 Volts

0.15 H.P., 440 Volts

Blade Speed

Meter/Minute

25,30,40

20,35,55,75

20,35,55,75

20,35,55,75

MACHINE SPECIFICATION

Saw blade-carbon or bi-metal

MM

2540 x 20 x 0.9

3000 x 27 x 0.9

3760 x 27 x 0.9

4100 x 27 x 0.9

Guide pulley diameter

MM

340

400

496

496

Floor space L x W x H

MM

1500 x 570 x 870

1630 x 570 x 870

2400 x 830 x 1050

2550 x 830 x 1050

Net weight

KG

272

322

450

520

Packed weight

KG

381 Approx.

431 Approx.

540 Approx.

610 Approx.



SPECIAL FEATURES
  • Less power consumption compared to Hacksaw.
  • Continuous cutting by means of circular endless blade.
  • Smoother and faster cutting compared to Hacksaw.
  • Easy and precise gravity manual feed control.
  • Makes optimum use of the blade due to rewelding of blade.
  • Special swing cut operation to cut larger section.
  • Efficient self centering vice.
  • Optional swivel vice for 30o/45o/60o angular cutting.
  • Special designed heavy duty gear box
  • Blade guide made of bearing & carbide tips
  • Less material wastage due to lesser blade thickness.
  • Good parallelism compared to hacksaw machine.
  •
